HDPE Reducer – Prime Quality for Seamless Diameter Transitions
The Prime HDPE Reducer is a versatile and durable fitting designed to connect pipes of different diameters while ensuring a smooth and efficient flow. Manufactured from premium High-Density Polyethylene (HDPE), this reducer is available in a size range from 20mm to 1200mm and a variety of Standard Dimension Ratios (SDR), including SDR17, SDR11, SDR9, and SDR7.4, to accommodate various pressure ratings and application needs. Built for precision and reliability, the HDPE Reducer is ideal for use in water systems, gas pipelines, industrial applications, and more. Choose Prime for high-quality piping solutions tailored for performance and versatility.
| Code | Dn | Dn1 | L | A | B | |
|---|---|---|---|---|---|---|
| HP-PN10-BF-RD-63X50 | 63 | 50 | 150 | 63 | 55 | |
| HP-PN10-BF-RD-75X63 | 75 | 63 | 150 | 70 | 63 | |
| HP-PN10-BF-RD-90X50 | 90 | 50 | 162 | 79 | 55 | |
| HP-PN10-BF-RD-90X63 | 90 | 63 | 168 | 79 | 63 | |
| HP-PN10-BF-RD-90X75 | 90 | 75 | 169 | 79 | 70 | |
| HP-PN10-BF-RD-110X32 | 110 | 32 | 169 | 82 | 55 | |
| HP-PN10-BF-RD-110X63 | 110 | 63 | 173 | 82 | 63 | |
| HP-PN10-BF-RD-110X75 | 110 | 75 | 181 | 82 | 70 | |
| HP-PN10-BF-RD-110X90 | 110 | 90 | 177 | 82 | 79 | |
| HP-PN10-BF-RD-125X90 | 125 | 90 | 183 | 87 | 79 | |
| HP-PN10-BF-RD-125X110 | 125 | 110 | 185 | 87 | 82 | |
| HP-PN10-BF-RD-140X110 | 140 | 110 | 220 | 92 | 82 | |
| HP-PN10-BF-RD-140X125 | 140 | 125 | 203 | 95 | 95 | |
| HP-PN10-BF-RD-160X32 | 160 | 32 | 202 | 98 | 70 | |
| HP-PN10-BF-RD-160X63 | 160 | 63 | 195 | 98 | 63 | |
| HP-PN10-BF-RD-160X75 | 160 | 75 | 204 | 98 | 70 | |
| HP-PN10-BF-RD-160X90 | 160 | 90 | 212 | 98 | 79 | |
| HP-PN10-BF-RD-160X110 | 160 | 110 | 211 | 98 | 82 | |
| HP-PN10-BF-RD-160X125 | 160 | 125 | 216 | 98 | 87 | |
| HP-PN10-BF-RD-160X140 | 160 | 140 | 203 | 98 | 93 | |
| HP-PN10-BF-RD-180X90 | 180 | 90 | 231 | 110 | 79 | |
| HP-PN10-BF-RD-180X110 | 180 | 110 | 219 | 110 | 82 | |
| HP-PN10-BF-RD-180X125 | 180 | 125 | 233 | 105 | 87 | |
| HP-PN10-BF-RD-180X160 | 180 | 160 | 229 | 105 | 87 | |
| HP-PN10-BF-RD-200X90 | 200 | 90 | 220 | 108 | 79 | |
| HP-PN10-BF-RD-200X110 | 200 | 110 | 228 | 112 | 82 | |
| HP-PN10-BF-RD-200X160 | 200 | 160 | 226 | 112 | 85 | |
| HP-PN10-BF-RD-200X180 | 200 | 180 | 245 | 112 | 105 | |
| HP-PN10-BF-RD-225X110 | 225 | 110 | 245 | 105 | 82 | |
| HP-PN10-BF-RD-225X160 | 225 | 160 | 249 | 105 | 90 | |
| HP-PN10-BF-RD-225X180 | 225 | 180 | 249 | 105 | 90 | |
| HP-PN10-BF-RD-225X200 | 225 | 200 | 246 | 105 | 90 | |
| HP-PN10-BF-RD-250X90 | 250 | 90 | 224 | 117 | 79 | |
| HP-PN10-BF-RD-250X110 | 250 | 110 | 221 | 108 | 82 | |
| HP-PN10-BF-RD-250X125 | 250 | 125 | 234 | 109 | 87 | |
| HP-PN10-BF-RD-250X160 | 250 | 160 | 244 | 110 | 98 | |
| HP-PN10-BF-RD-250X200 | 250 | 200 | 250 | 110 | 103 | |
| HP-PN10-BF-RD-250X225 | 250 | 225 | 231 | 105 | 90 | |
| HP-PN10-BF-RD-280X160 | 280 | 160 | 257 | 107 | 85 | |
| HP-PN10-BF-RD-280X200 | 280 | 200 | 257 | 110 | 103 | |
| HP-PN10-BF-RD-280X225 | 280 | 225 | 247 | 110 | 90 | |
| HP-PN10-BF-RD-315X110 | 315 | 110 | 241 | 115 | 82 | |
| HP-PN10-BF-RD-315X160 | 315 | 160 | 254 | 115 | 98 | |
| HP-PN10-BF-RD-315X200 | 315 | 200 | 253 | 115 | 92 | |
| HP-PN10-BF-RD-315X225 | 315 | 225 | 245 | 115 | 90 | |
| HP-PN10-BF-RD-315X250 | 315 | 250 | 246 | 115 | 90 | |
| HP-PN10-BF-RD-315X280 | 315 | 280 | 245 | 115 | 90 | |
| HP-PN10-BF-RD-355X200 | 355 | 200 | 270 | 100 | 100 | |
| HP-PN10-BF-RD-355X250 | 355 | 250 | 270 | 100 | 100 | |
| HP-PN10-BF-RD-355X280 | 355 | 280 | 260 | 100 | 100 | |
| HP-PN10-BF-RD-355X315 | 355 | 315 | 240 | 100 | 100 | |
| HP-PN10-BF-RD-400X200 | 400 | 200 | 260 | 100 | 100 | |
| HP-PN10-BF-RD-400X250 | 400 | 250 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-400X315 | 400 | 315 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-400X355 | 400 | 355 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-450X200 | 450 | 200 | 260 | 100 | 100 | |
| HP-PN10-BF-RD-450X250 | 450 | 250 | 260 | 100 | 100 | |
| HP-PN10-BF-RD-450X315 | 450 | 315 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-450X355 | 450 | 355 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-450X400 | 450 | 400 | 240 | 100 | 100 | |
| HP-PN10-BF-RD-500X400 | 500 | 400 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-500X450 | 500 | 450 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-560X500 | 560 | 500 | 260 | 100 | 100 | |
| HP-PN10-BF-RD-630X500 | 630 | 500 | 260 | 100 | 100 | |
| HP-PN10-BF-RD-710X630 | 710 | 630 | 250 | 100 | 100 | |
| HP-PN10-BF-RD-800X710 | 800 | 710 | 260 | 100 | 100 |
| Code | Dn | Dn1 | L | A | B | |
|---|---|---|---|---|---|---|
| HP-PN16-BF-RD-25×20 | 25 | 20 | 87 | 38 | 42 | |
| HP-PN16-BF-RD-32×25 | 32 | 25 | 96 | 42 | 42 | |
| HP-PN16-BF-RD-40×32 | 40 | 32 | 102 | 50 | 45 | |
| HP-PN16-BF-RD-50×40 | 50 | 40 | 119 | 56 | 52 | |
| HP-PN16-BF-RD-63×50 | 63 | 50 | 150 | 63 | 55 | |
| HP-PN16-BF-RD-75×63 | 75 | 63 | 150 | 70 | 63 | |
| HP-PN16-BF-RD-90×50 | 90 | 50 | 162 | 79 | 55 | |
| HP-PN16-BF-RD-90×63 | 90 | 63 | 168 | 79 | 63 | |
| HP-PN16-BF-RD-90×75 | 90 | 75 | 169 | 79 | 70 | |
| HP-PN16-BF-RD-110×32 | 110 | 32 | 169 | 82 | 55 | |
| HP-PN16-BF-RD-110×40 | 110 | 40 | 169 | 82 | 55 | |
| HP-PN16-BF-RD-110×50 | 110 | 50 | 166 | 82 | 55 | |
| HP-PN16-BF-RD-110×63 | 110 | 63 | 173 | 82 | 63 | |
| HP-PN16-BF-RD-110×75 | 110 | 75 | 181 | 82 | 70 | |
| HP-PN16-BF-RD-110×90 | 110 | 90 | 177 | 82 | 79 | |
| HP-PN16-BF-RD-125×90 | 125 | 90 | 183 | 87 | 79 | |
| HP-PN16-BF-RD-125×110 | 125 | 110 | 185 | 87 | 82 | |
| HP-PN16-BF-RD-140×110 | 140 | 110 | 220 | 92 | 82 | |
| HP-PN16-BF-RD-140×125 | 140 | 125 | 203 | 95 | 95 | |
| HP-PN16-BF-RD-160×32 | 160 | 32 | 202 | 98 | 70 | |
| HP-PN16-BF-RD-160×63 | 160 | 63 | 195 | 98 | 63 | |
| HP-PN16-BF-RD-160×75 | 160 | 75 | 204 | 98 | 70 | |
| HP-PN16-BF-RD-160×90 | 160 | 90 | 212 | 98 | 79 | |
| HP-PN16-BF-RD-160×110 | 160 | 110 | 211 | 98 | 82 | |
| HP-PN16-BF-RD-160×125 | 160 | 125 | 216 | 98 | 87 | |
| HP-PN16-BF-RD-160×140 | 160 | 140 | 203 | 98 | 93 | |
| HP-PN16-BF-RD-180×90 | 180 | 90 | 231 | 110 | 79 | |
| HP-PN16-BF-RD-180×110 | 180 | 110 | 219 | 110 | 82 | |
| HP-PN16-BF-RD-180×125 | 180 | 125 | 233 | 105 | 87 | |
| HP-PN16-BF-RD-180×160 | 180 | 160 | 229 | 105 | 87 | |
| HP-PN16-BF-RD-200×63 | 200 | 63 | 210 | 112 | 63 | |
| HP-PN16-BF-RD-200×90 | 200 | 90 | 220 | 108 | 79 | |
| HP-PN16-BF-RD-200×110 | 200 | 110 | 228 | 112 | 82 | |
| HP-PN16-BF-RD-200×160 | 200 | 160 | 226 | 112 | 85 | |
| HP-PN16-BF-RD-200×180 | 200 | 180 | 245 | 112 | 105 | |
| HP-PN16-BF-RD-225×110 | 225 | 110 | 245 | 105 | 82 | |
| HP-PN16-BF-RD-225×160 | 225 | 160 | 249 | 105 | 90 | |
| HP-PN16-BF-RD-225×180 | 225 | 180 | 249 | 105 | 90 | |
| HP-PN16-BF-RD-225×200 | 225 | 200 | 246 | 105 | 90 | |
| HP-PN16-BF-RD-250×90 | 250 | 90 | 224 | 117 | 79 | |
| HP-PN16-BF-RD-250×110 | 250 | 110 | 221 | 108 | 82 | |
| HP-PN16-BF-RD-250×125 | 250 | 125 | 234 | 109 | 87 | |
| HP-PN16-BF-RD-250×160 | 250 | 160 | 244 | 110 | 98 | |
| HP-PN16-BF-RD-250×200 | 250 | 200 | 250 | 110 | 103 | |
| HP-PN16-BF-RD-250×225 | 250 | 225 | 231 | 105 | 90 | |
| HP-PN16-BF-RD-280×160 | 280 | 160 | 257 | 107 | 85 | |
| HP-PN16-BF-RD-280×200 | 280 | 200 | 257 | 110 | 103 | |
| HP-PN16-BF-RD-280×225 | 280 | 225 | 247 | 110 | 90 | |
| HP-PN16-BF-RD-315×90 | 315 | 90 | 240 | 115 | 79 | |
| HP-PN16-BF-RD-315×110 | 315 | 110 | 241 | 115 | 82 | |
| HP-PN16-BF-RD-315×160 | 315 | 160 | 254 | 115 | 98 | |
| HP-PN16-BF-RD-315×200 | 315 | 200 | 253 | 115 | 92 | |
| HP-PN16-BF-RD-315×225 | 315 | 225 | 245 | 115 | 90 | |
| HP-PN16-BF-RD-315×250 | 315 | 250 | 246 | 115 | 90 | |
| HP-PN16-BF-RD-315×280 | 315 | 280 | 245 | 115 | 90 | |
| HP-PN16-BF-RD-355×200 | 355 | 200 | 270 | 100 | 100 | |
| HP-PN16-BF-RD-355×250 | 355 | 250 | 270 | 100 | 100 | |
| HP-PN16-BF-RD-355×280 | 355 | 280 | 260 | 100 | 100 | |
| HP-PN16-BF-RD-355×315 | 355 | 315 | 240 | 100 | 100 | |
| HP-PN16-BF-RD-400×200 | 400 | 200 | 260 | 100 | 100 | |
| HP-PN16-BF-RD-400×250 | 400 | 250 | 250 | 100 | 100 | |
| HP-PN16-BF-RD-400×315 | 400 | 315 | 250 | 100 | 100 | |
| HP-PN16-BF-RD-400×355 | 400 | 355 | 250 | 100 | 100 |
| Code | Dn | Dn1 | L | A | B | |
|---|---|---|---|---|---|---|
| HP-PN20-BF-RD-63X50 | 63 | 50 | 150 | 63 | 55 | |
| HP-PN20-BF-RD-75X63 | 75 | 63 | 150 | 70 | 63 | |
| HP-PN20-BF-RD-90X63 | 90 | 63 | 168 | 79 | 63 | |
| HP-PN20-BF-RD-110X32 | 110 | 32 | 169 | 82 | 55 | |
| HP-PN20-BF-RD-110×63 | 110 | 63 | 173 | 82 | 63 | |
| HP-PN20-BF-RD-110×75 | 110 | 75 | 181 | 82 | 70 | |
| HP-PN20-BF-RD-110×90 | 110 | 90 | 177 | 82 | 79 | |
| HP-PN20-BF-RD-125×110 | 125 | 110 | 185 | 87 | 82 | |
| HP-PN20-BF-RD-140×125 | 140 | 125 | 203 | 95 | 95 | |
| HP-PN20-BF-RD-160×32 | 160 | 32 | 202 | 98 | 70 | |
| HP-PN20-BF-RD-160×90 | 160 | 90 | 212 | 98 | 79 | |
| HP-PN20-BF-RD-160×110 | 160 | 110 | 211 | 98 | 82 | |
| HP-PN20-BF-RD-160×125 | 160 | 125 | 216 | 98 | 87 | |
| HP-PN20-BF-RD-160×140 | 160 | 140 | 203 | 98 | 93 | |
| HP-PN20-BF-RD-200×160 | 200 | 160 | 226 | 112 | 85 | |
| HP-PN20-BF-RD-200×180 | 200 | 180 | 245 | 112 | 105 | |
| HP-PN20-BF-RD-250×200 | 250 | 200 | 250 | 110 | 103 | |
| HP-PN20-BF-RD-250×225 | 250 | 225 | 231 | 105 | 90 | |
| HP-PN20-BF-RD-315×250 | 315 | 250 | 246 | 115 | 90 | |
| HP-PN20-BF-RD-315×280 | 315 | 280 | 245 | 115 | 90 |
| Code | Dn | Dn1 | L | A | B | |
|---|---|---|---|---|---|---|
| HP-PN25-BF-RD-110X32 | 110 | 32 | 169 | 82 | 55 | |
| HP-PN25-BF-RD-110X63 | 110 | 63 | 173 | 82 | 63 | |
| HP-PN25-BF-RD-110X75 | 110 | 75 | 181 | 82 | 70 | |
| HP-PN25-BF-RD-110X90 | 110 | 90 | 177 | 82 | 79 | |
| HP-PN25-BF-RD-125X110 | 125 | 110 | 185 | 87 | 82 | |
| HP-PN25-BF-RD-140X125 | 140 | 125 | 203 | 95 | 95 | |
| HP-PN25-BF-RD-160X32 | 160 | 32 | 202 | 98 | 70 | |
| HP-PN25-BF-RD-160X90 | 160 | 90 | 212 | 98 | 79 | |
| HP-PN25-BF-RD-160X110 | 160 | 110 | 211 | 98 | 82 | |
| HP-PN25-BF-RD-160X140 | 160 | 140 | 203 | 98 | 93 | |
| HP-PN25-BF-RD-200X160 | 200 | 160 | 226 | 112 | 85 | |
| HP-PN25-BF-RD-200X180 | 200 | 180 | 245 | 112 | 105 | |
| HP-PN25-BF-RD-250X200 | 250 | 200 | 250 | 110 | 103 | |
| HP-PN25-BF-RD-250X225 | 250 | 225 | 231 | 105 | 90 | |
| HP-PN25-BF-RD-315X250 | 315 | 250 | 246 | 115 | 90 | |
| HP-PN25-BF-RD-315X280 | 315 | 280 | 245 | 115 | 90 |
